LASER-CUT HIGH QUALITY STEEL PLATE BODY
Made with 44 HRC high quality steel and laser-cut to ensure longer life and precision cutting. |
|
LASER-CUT SOUND DAMPENING SLOTS
Slots reduce vibrations and noise by 10% compared to blades without it. This feature improves cut quality and extends blade life. In full compliance with National Noise Emission Standards and Regulations. |
|
TENSIONING RING (∅250mm and above)
A visible tensioning ring on blade body provides stability during the cut and perfect concentricity during rotation. For improved performance, tensioning is fine-tuned according to machine/application. |
|
SILVER BRAZING
Silver Alloy Brazing prevents carbide from breaking during the cooling process and allows teeth to withstand high stress and impact especially when cutting harder woods and composite materials. |
|
INDUSTRIAL SINTERHIP HI-DENSITY CARBIDE
The SINTERHIP sintering process (Hot Isostatic Pressing) uses high temperature (up to 3500°F) and high pressure (up to 1500 psi) to fully consolidate carbide thereby resulting in a porosity-free product ensuring longer cutting life over traditional carbide and less risk of breakages. |
PRECISION SHARPENING
Each tooth is precision ground on a multi-axis CNC machine creating perfect edge angles that provide extra-clean cutting performance and extended life. Featuring less than 0.35 μm Rmax in edge roughness. |
|
|
ORANGE SHIELD® NON-STICK PTFE COATING
- Protects against corrosion and rust. - Reduces resin and residue build-up. - Reduces overheating and blade drag. - Improves performance and cutting life. |
Item Code | Description | D | B | PH | Z | K | P | α | β |
---|---|---|---|---|---|---|---|---|---|
292.160.56H
|
Ultra Finish - For FESTOOL® Machines | 160 | 20 | 2/6/32 | 56 | 2.2 | 1.6 | 15 | ATB 15 |
292.165.56H
|
Ultra Finish - Ideal for Track Saw | 165 | 20 | 2/6/32 | 56 | 2.2 | 1.6 | 15 | ATB 15 |
292.190.64M
|
Ultra Finish | 190 | 30 | 2/7/42 | 64 | 2.6 | 1.6 | 15 | ATB 15 |
285.064.08M
|
Fine Finish - Saw Blade with Dampening Slots without Fill | 200 | 30 | COMBI3 | 64 | 3.2 | 2.2 | 5 | ATB 15 |
292.210.64M
|
Fine Finish - For FESTOOL® Machines | 210 | 30 | 2/7/42 | 64 | 2.8 | 1.8 | 15 | ATB 15 |
292.216.80M
|
Ultra Finish - For FESTOOL® Machines | 216 | 30 | 2/7/42 | 80 | 2.8 | 1.8 | -5 Neg. | ATB 15 |
292.230.64M
|
Fine Finish - For FESTOOL® Machines | 230 | 30 | 2/7/42 + 2/10/60 | 64 | 2.8 | 1.8 | 15 | ATB 15 |
294.080.11M
|
Fine Finish -Saw Blade With Dampening Slots Without Fill - For FESTOOL® Machines | 260 | 30 | COMBI3 | 80 | 2.5 | 1.8 | -5 Neg. | ATB 15 |
