ITK PLUS® Finish Blades

P050/6036_P070/8040

INDUSTRIAL SINTERHIP HI-DENSITY CARBIDE
The new process SinterHIP (high temperature 3500°F and high pressure 1500 psi)
creates a porosity-free and Hi-Density carbide which provides a longer cutting life than tradition carbide.
TRI-METAL BRAZING
The Silver-Copper-Silver tri-metal brazing process lets the teeth
with stand the severe impact caused by cutting harder woods and composite material.
NON-STICK ORANGE SHIELD® COATING
Keeps the blade running cool, reduces pitch build up and protects against corrosion.
Ideal for all types of wood including wet lumber.
  LASER-CUT HEAT EXPANSION SLOTS
Engineered to allow the blade to expand when heat build-up occurs from use,
preventing blade warping.
Unique patented dynamic balancing several orders of magnitude above
and beyond that which is currently available in the marketplace.
  TENSIONING RING (10” and above)
A visible tensioning ring on the blade provides stability while cutting
and perfect concentricity during rotation.
PRECISION MIRROR FINISH SHARPENING
Each tooth is ground to razor sharp precision on a multi-axis CNC machine
which creates perfect edge angles, guaranteeing extra-clean cuts and extended life.
Featuring less than 0.25 μm Rmax in edge roughness.



Variations
Filter
Item Code D Z B β K P α
P06036
P06036 6-1/2 36 5/8 ATB 10 + SHEAR 0.067 0.039 20
P07040
P07040 7-1/4 40 5/8 ATB 10 + SHEAR 0.067 0.039 18
P07040-X10
P07040-X10 7-1/4 40 5/8 ATB 10 + SHEAR 0.067 0.039 18
P08040
P08040 8-8-1/4 40 5/8 ATB 15 0.094 0.063 10
